รายละเอียดสินค้า:
|
| ความสามารถในการเชื่อม: | ดี | กำลังโหลดพอร์ต: | ท่าเรือเซี่ยงไฮ้ |
|---|---|---|---|
| พื้นผิว: | รีดร้อน / ดึงเย็น / ขัดเงา | เส้นผ่านศูนย์กลาง: | 10 - 500 มม. |
| คลังสินค้า: | ใช่ | โลหะผสมหรือไม่: | อัลลอย |
| ชื่อผลิตภัณฑ์: | เหล็กเส้นกลมอัลลอยด์ | ความแข็งแกร่ง: | สูง |
| รูปร่าง: | กลม | หมายเลขรุ่น: | เหล็กเส้นกลม |
| บรรจุุภัณฑ์: | แพ็คเกจ Seaworthy | ความต้านทานการกัดกร่อน: | สแตนเลสมีความต้านทานสูง ขึ้นอยู่กับเกรดวัสดุ |
| คุณสมบัติทางกายภาพ: | ความถ่วงจำเพาะ 7.85 | สี: | ดำหรือสว่าง |
| น้ำหนักเปอร์มิเตอร์: | แตกต่างกันไปตามเส้นผ่านศูนย์กลาง (เช่น 7.85 กก./ม. สำหรับเส้นผ่านศูนย์กลาง 10 มม.) |
Special Steel Round Bar
| Grade | Spec | Dimension | Steel Grade | Application industry | |
| Special Steel Round Bar | Quality carbon structural steel | GB/T699 JIS G 4051 ASTM A29 SAE,EN10083 (Others) | 12-260 | 10# ,20#,45#, 65Mn,SAE1080,S45C,etc | For Manufacturing of All Kinds of Bearing Parts, Connecting Rod. Rigging Metal Tools etc. |
| Low alloy high-strength steel | GB/T1591,(Others) | 13-260 | Q355 series,Q460C,etc | Mechanical,Car,Engineering machinery | |
| Alloy structural steel | GB/T3077,JIS,ASTM A29, EN10083,(Others) | 13-260 |
20Mn2-45Mn2,25MnV,27SiMn-42SiMn, 20Cr-40Cr,12CrMo-42CrMo,20CrMn,40CrMn,SCr420,SCr440, SCM420,SCM440, 41Cr4,20CrMoA,30CrMoA,20Cr2MoA, 20CrNiMo,20Cr2Ni4A,SAE4340, 20Cr2Ni4A,30CrMnSiA etc |
Mechanical,Car,Bridge, Petrochemical industry |
|
| Bearing steel | GB/T18254,(Others) | 14-200/5-25 wire rod and cold drawn wire |
GCr15,GCr15SiMn,C&U1,C&U2,GCr15-JN,SCP52100,SCPSS52100, GCr15S700,100CrMn6,SUJ2, SUJ2S1,SAE1055,S55C, G20CrNiMoA(SAE8620),GCr15etc |
Mechanical ,Car ,Electric machinery,Engineering machinery etc | |
| Spring Steel | GB/T1222,JIS,SAE,EN,(Others) | 13-120 |
60Si2MnA,60Si2CrA,60Si2CrVA,55CrMnA, 50CrVA,SUP9, SUP9A ,SUP11A, 55Cr3 ,51CrV4 , 52CrMoV4 ,SAE5160 SAE6150 ,SAE9254, 60SiCrVAT, 52CrMoV4 ,55SiCr etc |
Car,High Speed railway,Locomotive | |
| Round billet | 300mm-600mm ( According to the different requirement) | ||||
| Large section bar | 80mm-350mm ( According to the different requirement) | ||||
Hot Rolled and Forged 18Cr2Ni4WA Alloy Steel Round Bar Structure Application Diameter 20 - 300mm
Products Specification
| Products Name | 18Cr2Ni4WA Alloy Steel Round Bar |
| Diameter | 20 - 350 mm |
| Length | 6m or custom cutting any length as request |
| Type | Hot Rolled |
| Brand | BAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc |
| MOQ | 1 Ton |
| Loading Port | Shanghai Port |
| Packing | packing by steel wire rope |
| Deliver time | 5 - 7 days for stock materials |
| Other Grade |
Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov,15CrMo ,20Cr,40Cr,20CrMo,35CrMo,42CrMo,40CrNiMo,GCr15,65Mn,50Mn, 50Cr,3Cr2W8V,20CrMnTi,25Cr2MoVA,5CrMnMo ,38CrMoAl, 30CrMnSiA,B16,31CrMoV9 |
| Standard | ASTM GB EN DIN |
| Application | Structure and Industrial |
Hot Rolled and Forged 18Cr2Ni4WA Alloy Steel Round Bar Structure Application Diameter 20 - 300mm
18Cr2Ni4WA is a high-strength, high-durability alloy steel commonly used in various structural applications. The alloy composition includes Chromium (Cr), Nickel (Ni), and Molybdenum (Mo), which endow the steel with exceptional mechanical properties. Hot rolled and forged 18Cr2Ni4WA alloy steel round bars with diameters ranging from 20mm to 300mm are widely utilized in industries requiring robust materials capable of withstanding heavy mechanical stress, corrosion, and high-temperature environments.
This alloy steel is particularly renowned for its excellent performance in applications such as machinery manufacturing, heavy-duty equipment, automotive components, and aerospace engineering. The steel is produced through advanced forging and hot rolling processes, which significantly enhance its strength, fatigue resistance, and overall reliability.
The key elements that make up the 18Cr2Ni4WA alloy steel are:
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.18 - 0.22 |
| Chromium (Cr) | 1.8 - 2.2 |
| Nickel (Ni) | 3.8 - 4.2 |
| Molybdenum (Mo) | 0.2 - 0.4 |
| Silicon (Si) | 0.3 - 0.6 |
| Manganese (Mn) | 0.5 - 0.8 |
| Phosphorus (P) | ≤ 0.035 |
| Sulfur (S) | ≤ 0.035 |
| Tungsten (W) | 0.4 - 0.7 |
This unique combination of alloying elements provides excellent toughness, wear resistance, and high-temperature stability.
The mechanical properties of 18Cr2Ni4WA alloy steel round bars can be summarized as follows:
| Property | Value |
|---|---|
| Tensile Strength | 800 - 1000 MPa |
| Yield Strength | 650 - 850 MPa |
| Elongation | ≥ 15% |
| Hardness (HB) | 250 - 300 |
| Impact Toughness | ≥ 30 J at -20°C |
| Modulus of Elasticity | 200 GPa |
These mechanical properties ensure that the 18Cr2Ni4WA alloy steel is capable of withstanding high levels of stress and wear while maintaining structural integrity under extreme conditions. The tensile strength, yield strength, and impact toughness make it ideal for use in critical structural and engineering applications where reliability is essential.
The versatility and superior mechanical properties of 18Cr2Ni4WA alloy steel make it suitable for a variety of structural and engineering applications. Some of the most common uses include:
Automotive Industry:
Manufacturing of engine components, drive shafts, and gears.
Production of high-performance suspension parts, bearing housings, and crankshafts.
Aerospace Industry:
Aircraft landing gear components, turbine engine parts, and structural components.
Parts requiring high tensile strength and resistance to fatigue and high temperatures.
Heavy Machinery and Equipment:
Construction machinery such as bulldozer blades, excavator arms, and hydraulic cylinders.
Mining equipment and other high-load bearing components.
Mechanical Engineering:
Shafts, axles, and couplings that require high mechanical strength and resistance to wear and tear.
Gear shafts and other rotating equipment parts.
FAQ :
Q:Do you provide free samples?
A: Yes, we can provide a free sample for testing,buyer should bear all the shipping costs.
Q:Do you accept small orders?
A:You don't need to worry about this problem, just consult
Q:Do you accept the third party inspection?
A: Yes absolutely we accept.
Q:How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by Linxu piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
Q:What are the advantages of your company?
A:(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements.
Q:What is your terms of payment ?
A:Payment<=1000USD,100% in advance.Payment>=1000USD,30% T/T in advance ,balance based on BL copy or LC at sight.
Q:How about our price?
A:Our price is very competitive because we are a factory.Pls feel free to contact us if you are interested in our products.
Q:How long is your delivery time?
A:Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality
assurance.Usually the delivery time is within 7 days after we received your deposit.
